Industrial Powder Spray Machine 50W Electrostatic Powder Coating Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | THD |
| Certification: | CE |
| Model Number: | 003 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1unit |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | shockproof carton packing |
| Delivery Time: | 5-8 working day |
| Payment Terms: | Western Union, T/T, L/C |
| Supply Ability: | 100piece/piece per month |
|
Detail Information |
|||
| Brand Name: | THD | Model: | THD003 |
|---|---|---|---|
| Weight: | 31 | Max Output Voltage: | 40-80KV |
| Polarity: | Negative | Operation Way: | Manual Powder Coating Equipment |
| High Light: | 50W Powder Spray Machine,Electrostatic Powder Spray Machine,Industrial Electrostatic Powder Coating Machine |
||
Product Description
50w Electrostatic Powder Spray Machine Powder Spray Machine For Industrail System
Product Introduction
The spray equipment uses an automatic current feedback circuit and adds a pulse control circuit. The gas control part adopts two-stage gas source filtration, voltage regulation and air pressure adjustment, all designed as preset adjustments. The powder output is more uniform, the atomization is better, and the dead angle is much better.
Use the digital panel forwarding key. It can change the pulse and normal function, and voltage current display function. With a very high powdering rate and the best coating quality.
Product Specification
MODEL | THD001 | THD002 | THD003 | THD004 |
Dimension | 64*46*98 | 64*46*98 | 64*46*98 | 64*46*98 |
Weight | 32 | 31 | 31 | 32 |
Input power | 50 | 34 | 34 | 34 |
Input voltage | 110/220VAC | 110/220VAC | 110/220VAC | 110/220VAC |
Frequency | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
Max Output voltage | 0-100KV | 0-100KV | 0-100KV | 0-100KV |
Hopper volume | 55L | 55L | 55L | 55L |
Polarity | Negative | Negative | Negative | Negative |
characteristics
The Safety Rules
1. You must read the instructions carefully before use.
2. The operator must wear appropriate labor protection supplies before operation.
3. The spray equipment and the workpiece to be sprayed must be well grounded in the work site.
4. Gloves are not allowed when the worker is in contact with the spray gun.
5. No smoking is allowed in the workplace, and fire is prohibited.
6. After work finished, turn off the power before cleaning the gun and replacing parts.
