Infrared Catalytic BBQ Radiant Burner Roaster LPG Gas Burner For Pizza Oven
Product Details:
| Place of Origin: | China |
| Brand Name: | THD |
| Certification: | CE |
| Model Number: | 405 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1unit |
|---|---|
| Price: | USD Nogotiable |
| Packaging Details: | shockproof carton packing |
| Delivery Time: | 5-8 working day |
| Payment Terms: | T/T, Western Union, T/T, L/C |
| Supply Ability: | 1000piece/piece per month |
|
Detail Information |
|||
| Model: | THD405 | Gas Type: | NG/ LPG |
|---|---|---|---|
| Weight (KG): | 0.77 | Size: | 405*80*55mm |
| Advantage: | 20% Gas Saved | Application: | Industrial Oven, Powder Coating Oven |
| Material: | Aluminized Steel Sheet | ||
| High Light: | Catalytic BBQ Radiant Burner,Infrared BBQ Radiant Burner,LPG Gas Burner For Pizza Oven |
||
Product Description
Gas Lpg Infrared Catalytic Radiant BBQ Burner Roaster Burner For Pizza Oven
Product Introdution
|
Model |
Dimension | N.W. | Gas Type | Heat Output | Gas consumption | Power |
|
|
mm | kg | Kcal/h | NG LPG | KW | |
|
THD405 |
405*80*55mm | 0.77 | NG LPG | 2065 | 0.24 0.21 | 2 |
Infrared Burner covers a process rare earth as catalyst, make the flamelessburning occurred at the ceramic surface and radiate directly. So, the energy transfer rate is much higher than common ceramic burner.
product specification
Gas BBQ Grill Infrared Ceramic Burner Main Material:
1.Shell: Aluminized steel sheet
2. Radiant part: cordierite honeycomb plates with black processed rare-earth catalyst coated
3. Nozzle: brass
4. Up cover: Aluminized steel sheet
Our Advantage
1. Easy being fixed.
2. Energy savings can be up to 20% per year
3. Environmental protection: CO≤80ppm;NOx≤10ppm;CHx≤50ppm
4. No need for a long and expensive preheating, it will reach comfort temperature very quickly.
5. Long useful time: ≥11000hr
6. Easy to clean
7. It can cut off the gas automatically and protect the burner when the flameout.
8. Silent, light and compact
9. High efficiency: it can come to working condition in 8seconds.
Application
The application range of this product is very wide. It is mainly installed on the innermost stove wall of the oven. The combustion surface and horizontal plane are 90 degrees angle, so it is used to call it: "infrared back furnace".
Our Company
Chongqing Haodong Technology Co.,LTD is the first one and only one company who apply rare-earth catalytic combustion technology on infrared burner & heater, this kind of technology could save 20% energy than non-catalytic infrared heater. Now we are specialized in Gas Burner, Infrared Burner, Gas Heater, BBQ Burner, Bakary Oven Burner, Industrial Burner..
