Infrared Bread Bakery Oven Gas Burner Energy Saving LPG Butane Propane Natural Gas
Product Details:
| Place of Origin: | China |
| Brand Name: | THD |
| Certification: | CE |
| Model Number: | HD600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard carton; Outer carton size: 630x250x290cm |
| Delivery Time: | 3-7 workdays |
| Payment Terms: | T/T, Western Union, PayPal, Dragon Pay, L/C |
| Supply Ability: | 5000pcs/month |
|
Detail Information |
|||
| Gas Type: | LPG, Natural Gas, Butane, Propane | Dimension: | 600*175*220mm |
|---|---|---|---|
| Advantage 1: | 20% Gas Saving Than Normal Infrared Gas Burner | Advantage 2: | Conveyor Rate: Above 95% |
| Technology: | Covered With Rare Earth Catalyst On Combustion Plate | Heat Output: | 9.4KW/h, 8120Kcal/hr |
| Warranty: | 1 Year Without Human Factor | Application: | Biscuit Line, Puff Food Line, Bread Baking Oven Etc |
| High Light: | Energy Saving Bakery Oven Gas Burner,Butane Bakery Oven Gas Burner,Propane Infrared Gas Burner |
||
Product Description
Energy Saving Infrared Bakery Oven Gas Burner For Bread Baking Equipment
Company profile
We have established long term business relation with many customers all over the world due to good quality product, attractive price, timely shipment, perfect after – sale service.
Our company performs in accordance with Chinese National Standards (GB) in China and quality assurance standards are implemented for overseas distribution.
Description
Adopt the high quality import cordierite porous plate, adding rare earth catalyst to produce high quality infrared catalytic burner. Main advantages are energy-saving and reducing consumption, improving productivity, long life, easy to install and maintain, environmental protection and so on.
Specifications
| MODEL | Dimension | Weight | Gas Type | Heat Output | Consumption | ||
| mm | kg | KW/h | Kcal/hr | NG(m3/h) | LPG(kg/h) | ||
| HD82 | 219*164*108 | 4.8 | NG/LPG | 3.1 | 2700 | 0.24 | 0.24 |
| HD101 | 690*80*115 | 6.9 | NG/LPG | 3.9 | 3380 | 0.3 | 0.29 |
| HD162 | 570*130*175 |
5.9
|
NG/LPG | 6.3 | 5400 | 0.49 | 0.47 |
| HD410 | 410*175*220 | 8 | NG/LPG | 6.3 | 5400 | 0.49 | 0.47 |
| HD242 | 840*130*175 |
7.5
|
NG/LPG | 9.4 | 8120 | 0.75 | 0.71 |
| HD600 | 600*175*220 | 11.7 | NG/LPG | 9.4 | 8120 | 0.75 | 0.71 |
| HD262 | 930*130*175 |
7.8
|
NG/LPG | 10.9 | 9360 | 0.8 |
0.82
|
Material
Combustion plate: covered with rare earth catalyst which can save 20% gas energy, this catalyst only used by us
System for burner with ignition parts
Advantages
♦Energy efficient, as high as 20% gas can be saved every year
♦ Conveyor rate: above 95%
♦Reliability, Silent, light and compact
♦Lower emissions to the air in the barn, CO≤80ppm;NOx≤10ppm;CHx≤50ppm
♦Low maintenance, usually only need to keep the combustion plate clean
♦ Withstands high pressure washing
♦Flame-out protection device
♦Lifespan: ≥11000hr
Application
1. Food baking oven: Biscuit line, puff food oven, tea drying, vegetable dehydration etc;
2. Glove thermoforming oven: disposable glove(nitrile, latex gloves) process line etc;
3. Industrial oven: powder coating oven, glove thermoforming line, tunnel oven, curing oven, pre-heat process etc;
